ИБП Vertiv

Advantages - Quick real-time view of parametric data and system states. - Quick alarm notification for quick resolution of events. - Know the environmental conditions in your data center to make informed and effective decisions. - Flexible communication regardless of the device protocol. - Peace of mind, knowing that the data is transmitted in a secure way. - Save time on configuring and updating the firmware on managed devices. Functions - Provides web access to installed devices through popular web browsers-Microsoft Internet Explorer, Mozilla Firefox, Google Chrome and Safari. - Provides alarm notifications via email and text messages. - Supports environmental monitoring with Liebert SN

GXTRT-3000IRT2UXL Power (VA/W) 3000/2700 Dimensions (mm) Unit (W x D x H) 438 x 632 x 88 Weight (kg) Block 27.6 Input AC current parameters* Rated voltage 230 V AC The range is 120-300 VAC. current Frequency 40-70 Hz IEC60320 C20 Power Input Connector Output AC current parameters Output connectors IEC60320 C13 x 6 IEC60320 C19 x1 Output voltage and regulation (standard 230 V, user selectable) 220/230/240 V AC. current ± 1 % The waveform of the sine wave Overload in the power supply network

Device Type Network Management card for SNMP and remote Web access Appointment The remote control adapter is used to control a wide range of parameters, alarms and notifications. The card not only improves work efficiency by providing the ability to view the connected system one-to-one, but also provides a convenient way to configure and update devices. Compatibility Suitable for GXT MT+ CX series / GXT MT+ series / GXT RT+ series, Vertiv Communication ports (RS232) DB9F, DTE RJ45 Power requirements DC inputs: 9 to 12 VDC, maximum 3.6W, power consumption: maximum 6 VA (1.75W)

Type Inverter (online) The form factor Rack (in the rack) Input voltage 1 phase (230 V) Input voltage range 176 – 288 V Peak output power 6000 VA Rated output power 6000 Watts The output waveform is pure sine wave (PSW) Dimensions (HxWxD) 217x430x630 mm Height (unit) 5 U Weight 70.8 kg

Type Inverter (online) The form factor Rack (in the rack) Operating time at full load 3.3 min Operating time at full load 10.8 min Input voltage 1 phase (230 V) Input voltage range 115 – 288 V Peak output power 3000 VA Rated output power 3000 Watts The output waveform is pure sine wave (PSW) Dimensions (HxWxD) 85x430x470 mm Height (unit) 2 U Weight 28.2 kg

Technical characteristics of 10 kVA GXT5-10KIRT5UXLE Power (VA/W) 10,000 VA/10,000 W Dimensions, inches (mm) Unit (W x D x H) 16,9×24,8×8,5(430×630×217) Weight, pounds (kg) Ag-t 298 (135.2) Input AC current parameters Rated operating frequency 50 or 60 Hz (Factory default value: 50) Voltage range 230 V AC Input cable With cable connection (shared or split bypass) Output AC current parameters Output connectors With cable connection 4(C19), 4 (C13) Default AC frequency 230 V AC 50 Hz or 60 Hz, Nominal value Curve shape (battery life) Sinusoidal Overload in the power supply network >150 %, min. 200 ms; 125-150 % for 60 seconds; 105-125 % for 5 minutes; ≤105 % continuously Battery Type

Type Inverter (online) The form factor Rack (in the rack) Operating time at full load 3.2 min Operating time at full load is 9 minutes Input voltage 1 phase (230 V) Input voltage range 120 – 300 V Peak output power 1500 VA Rated output power 1350 Watts The output waveform is pure sine wave (PSW) Full charge time 240 min Dimensions (HxWxD) 88x438x462 mm Height (unit) 2 U Weight 14.5 kg

Technical characteristics-models 2 in rack/floor version EDGE Model Number-22000IRT2UXL Power (VA/W) 2200 VA/1980 W Dimensions, mm Unit (W x D x H) 438 x 510 x 88 Delivery, W x D x H 600 x 800 x 240 Weight, kg Ag-T 27 In a package of 35 Input AC current parameters Rated voltage values of 230 V Voltage when working without a battery (default 230 V) 166-278 Frequency range (Hz) 55-65 IEC60320 C20 Input Power Connection Overvoltage protection (J): 624 Output AC current parameters Output connectors (3 + 1) IEC320-C13+1 IEC320-C19 Output sockets-controlled Yes, 1 group Waveform (when running on batteries) Sinusoid The switching time is usually from 4 to 6 ms Output overload (AC mode) 106% - 125%
