Сигнализации и Smart Hub Dahua

Input/OutputWireless Zone150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)PortNetwork Port1 × RJ-45 10 M/100 M Ethernet portStorage BatteryBuilt-in lithium batteryIndicator Light1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Button1 × reset, 1 × power, 1 × APBuzzerBuilt-inFunctionTamper AlarmYesVideo LinkageYesNetwork ProtocolTCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTPRemote UpgradeCloud updateArm and DisarmApp; keyfob; schedulePower Failure Protection for Configured ParametersYesUser ManagementShare function for App usersCacheMax. 50 entries (ANR)Low Battery AlarmYesSearchSearch for push messages, device status, and program version,

Input/OutputWireless Zone150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)PortNetwork Port1 × RJ-45 10 M/100 M Ethernet portNetwork ModeSingle SIM 2G (GSM:B3/B8); dual SIM single standbyStorage BatteryBuilt-in lithium batteryIndicator Light1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Button1 × reset, 1 × power, 1 × APBuzzerBuilt-inFunctionTamper AlarmYesSMSYes (up to 5 phone numbers)Calling AlarmYes (up to 5 phone numbers)Video LinkageYesNetwork ProtocolTCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTPRemote UpgradeCloud updateArm and DisarmApp; keyfob; schedulePower Failure Protection for Configured ParametersYesUser ManagementShare

Input/OutputWireless Zone150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)PortNetwork Port1 × RJ-45 10 M/100 M Ethernet portNetwork ModeSingle SIM (GSM:900/1800MHz, WCDMA:B1/B5/B8, LTE-FDD:B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41); dual SIM single standbyStorage BatteryBuilt-in lithium batteryIndicator Light1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Button1 × reset, 1 × power, 1 × APBuzzerBuilt-inFunctionTamper AlarmYesSMSYes (up to 5 phone numbers)Calling AlarmYes (up to 5 phone numbers)Video LinkageYesNetwork ProtocolTCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTPRemote UpgradeCloud updateArm and DisarmApp; keyfob; schedulePower

PortIndicator Light1 × green alarm indicatorButton1 × power buttonProtection Zone1-channel dry contact inputFunctionTampering AlarmYesRemote UpgradeCloud updateLow Battery AlarmYesTest ModeYesSearchSignal strength detectionWirelessCarrier Frequency868.0 MHz–868.6 MHzCommunication DistanceUp to 1,200 m (3,937.01 ft) in an open spaceCommunication MechanismTwo-wayFrequency HoppingYesEncryption ModeAES128GeneralPower Supply ModeCR123A batteryPower ConsumptionMax. 125 mWOperating Temperature–10 °C to +55 °C (+14 °F to +131 °F) (indoor)Operating Humidity10%–90% (RH)Dimensions100.2mm × 20.8mm × 20.3mm (3.94" × 0.82" ×0.80")Package Dimensions135.0 mm × 98.5 mm × 27.8mm (5.31" ×

FunctionIndicator Light1 × green alarm indicator12 × alarm LED groupsButton1 × power switchBuzzer1 × buzzerRemote UpdateCloud updateLow Battery DetectionYesBattery Level DisplayYesTamperYesSignal Strength7WirelessCarrier Frequency868.0 MHz–868.6 MHzCommunication DistanceUp to 1,600 m (5,249.34 ft) in an open spaceCommunication MechanismTwo-wayFrequency HoppingYesEncryption ModeAES128GeneralPower Supply ModeBattery (default), 12 VDCBattery ModelCR123ABattery Life4 CR123A batteries can be used for 3.4 years (if triggered fortnightly and the alarm sounds for 120 s each time with a battery efficiency of 80%)Operating Temperature–25 °C to +60 °C (–13 °F to +140 °F)Operating

Input and OutputWireless Protection ZoneHub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)PortBuzzerHub: Built-inButtonHub: 1 × reset, 1 × power, 1 × APKeyfob: 4 (Home, Away, Disarm, and SOS)Door Detector: 1 × power buttonPIR Detector: 1 × power buttonIndicator LightHub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)Door Detector: 1 × green alarm indicatorPIR Detector: 1 × green alarm indicatorStorage batteryHub: Built-in lithium batteryNetwork PortHub: 1 × RJ-45 10 M/100 M Ethernet portFunctionNetwork ProtocolHub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and

Input and OutputWireless Protection ZoneHub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)PortBuzzerHub: Built-inButtonHub: 1 × reset, 1 × power, 1 × APKeyfob: 4 (Home, Away, Disarm, and SOS)Door Detector: 1 × power buttonPIR Detector: 1 × power buttonIndicator LightHub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)Door Detector: 1 × green alarm indicatorPIR Detector: 1 × green alarm indicatorStorage batteryHub: Built-in lithium batteryNetwork ModeHub: Single SIM (GSM:900/1800MHz); dual SIM single standbyNetwork PortHub: 1 × RJ-45 10 M/100 M Ethernet

Input and Output Wireless Protection Zone Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs) Port Buzzer Hub: Built-in Button Hub: 1 × reset, 1 × power, 1 × APKeyfob: 4 (Home, Away, Disarm, and SOS)Door Detector: 1 × power buttonPIR Detector: 1 × power button Indicator Light Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)Door Detector: 1 × green alarm indicatorPIR Detector: 1 × green alarm indicator Storage battery Hub: Built-in lithium battery Network Mode Single SIM (GSM:900/1800 MHz, WCDMA:B1/B5/B8, LTE-FDD:B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41); dual SIM
